  Quick View

  Micro Converter HDMI to SDI 3G wPSU

  Connections
  SDI Video Outputs
  2 x SD, HD or 3G‑SDI.
  Automatically matches the HDMI input.
  HDMI Video Inputs
  HDMI Type A in.
  Multi Rate Support
  Auto detection of SD or HD.
  Updates, Configurations and Power
  USB Type‑C.
  Reclocking
  Yes
  Power Requirements
  Power Supply
  +5V universal power supply included with international socket adapters for most countries.
  Power Consumption
  2 W
  Operational Voltage Range
  4.4 to 5.25V DC
  Environmental Specifications
  Operating Temperature
  0° to 40° C (32° to 104° F)
  Storage Temperature
  -20° to 60° C (-4° to 140° F)
  Relative Humidity
  0% to 90% non-condensing

  Read more

  Compare
•

  Quick View

  Micro Converter BiDirectional SDI/HDMI 3G

  Connections
  SDI Video Inputs
  1 x SD, HD or 3G-SDI.

  SDI Video Outputs
  Automatically matches the HDMI video input.

  HDMI Video Inputs
  HDMI Type A in.

  HDMI Outputs
  HDMI Type A out.
  Multi Rate Support
  Auto detection of SD or HD.

  Updates, Configurations and Power
  USB Type‑C.

  Reclocking
  Yes

  Read more

  Compare
•

  Quick View

  SEETEC SDI⇌HDMI Cross Converter SCH

  Model
  SCH (SDI ⇌ HDMI Cross Converter)

  Input
  1 X BNC 3G/HD/SD-SDI
  1 X HDMI HDMI

  Output
  2 X BNC 3G/HD/SD-SDI
  1 X HDMI HDMI

  SDI Support Format
  3G-SDI:1080P(60/59.94/50)
  HD-SDI:1080P(30/29.97/25/24)
  1080I(60/59.94/50)
  1080PsF24
  720P(60/59.94/50/30/25/24)

  HDMI Support Format
  1080P(60/59.94/50/30/29.97/25/24)
  1080I(60/59.94/50)
  1080PsF24
  720P(60/59.94/50/30/25/24)

  General
  Power Consumption ≤4.2W
  Input Voltage DC 5～24V
  Connector DC 12V
  Battery Plate F970 (Standard); D28S, E6 (Optional)
  WorkingTemperature -20°C~60°C
  Storage Temperature -30°C~70°C
  Unit Size (mm) 108.5L×78.8H×23D
  Unit Weight 230g/ 260g (With F970 Plate)

  Read more

  Compare
•

  Quick View

  Converters Up / Down / Cross Converter DAC-70

  Conversion   VGA/HDMI/SDI to HDMI/SDI
  Multi-format Up/Down/Cross
  Video Inputs   1x VGA, 1x HDMI,
  1x 3G/HD/SD-SDI (support Level A and Level B)
  Loop Through   Yes
  Video Outputs   2x 3G/HD/SD-SDI with embedded Audio (support Level A and Level B)
  1x HDMI
  Audio Inputs   2x RCA (Stereo Pair), 2x SDI/HDMI Audio embedded
  Audio Outputs   SDI embedded audio up to 8CH, 48KHz, PCM audio
  HDMI embedded audio up to 8CH, 48KHz, PCM audio
  Audio Format Selection   —-
  Audio Gain   —-
  Supported Video Input Formats   1080p(23.98/24/25/29.97/30/50/59.94/60Hz),
  1080psf(23.98/24/25/29.97/30Hz), 1080i (50/59.94/60Hz), 720p (50/59.94/60Hz),
  625i, 576p, 576i, 525i, 480p, 480i, 1920×1080(60Hz), 1280×720(60Hz), 1600×1200(60Hz), 1400×1050(60Hz), 1366×768(60Hz), 1280×1024(60Hz), 1024×768(60Hz), 800×600 (60Hz)
  Output Resolutions
  1080p(23.98/24/25/29.97/30/50/59.94/60Hz), 1080i (50/59.94/60Hz), 720p (50/59.94/60Hz),
  625i, 525i
  Equalizer   Yes
  Reclock   Yes
  SDI Cable Drive   Yes
  Updates and Configuration  1 x Mini USB
  Dimension (LxWxH)   112 x 85 x 45 mm
  Weight   0.4 kg
  Operating Temp. Range   0~40 °C
  Power   DC 12V, 6W
  What’s in the Box   1 x DAC-70
  1 x AD Switch DC 12V
  1 x DIP switch Pin 8 label

  Read more

  Compare
